SM15A 15inch 500W active full range loudspeaker< back

zoom in zoom out

SM15A is 2-way full range DSP active loudspeaker

build in DSP module, work stable, lightweight

plywood cabinet

customized LF + 3" HF

high powerful sound, good quality, good performance

suit for church, clud, disco, road show, wedding, university etc events.

Products Model:	SM 10A	SM 12A	SM 15A	SM 215A	SM 18SA	SM 218SA
LF driver unit Inch	10"	12"	15"	2 x 15"	18"	2 x 18"
HF drivers	1 x 1.4"	1 x 1.7"	1 x 3"	1 x 3"	/	/
Dispersion Angle (H * V)	80° X 50° Rotatable Horn, 4 Positions			/	/	/
RMS	300W	400W	500W	1100W	600W	1200W
Program / Peak power	600W /900W	800W /1200W	1000W 1500W	2200W / 3300W	1200W /2100W	2400W /3600W
Nominal MAX /Peak SPL	127dB	129dB	129dB	132dB	136dB	138B
Frequency Response( ±3dB)	45Hz - 20KHz	42Hz - 20KHz	40Hz - 20KHz	40Hz - 20KHz	25Hz - 250Hz	25Hz - 250Hz
Crossover Frequency point	2.1 KHz	2.0 KHz	1.9 KHz	1.9 KHz	150Hz	150Hz
Nominal Impedance	8 Ohms	8 Ohms	8 Ohms	4 Ohms	8 Ohms	4 Ohms
Input output inside amps	2* XLR- INPUT /LINK
LED indicators	Active / Signal / Clip / Protect
RS-485 / Network	RS-485 / Network, USB Connector to Coumputer,For DSP function operation
Protections	DC protect.High temperature .Short circuit protect, Soft startup protect, overload protect
Power amplifier Circuitry	Class D
Dimension WDH (mm)	351×505×316	390×595×358	465×695×456	440×785×400	570×830×695	570×1310×805
Net Weight (1pcs)	21kg	26kg	37kg	49kg	60kg	97kg

. Mid or Larger clubs, disco bars hotel and restaurants
. Stadium Sports and mid. large exhibition spaces.
. Theater places performance expand sound systems.
. Audio & video presentations sound systems.
. Fixed Installations system and Live sound reinforcement
