SN12, SN15 is 2-way full range loudspeaker
plywood cabinet
customized in ferrite woofer and driver
high powerful, good sound, suit for church, wedding, club, disco, road show etc events
Products Model: SN12 SN15 LF woofer unit 1 x 12" (φ75mm) 1 x 15" (φ75mm) HF drivers 1 x 1.7" 1 x 3" Horn & Exit throat Size 1" 1.5"(38mm) Dispersion Angle (H * V) 80° X 50° 80° X 50° RMS / Program 400W 500W Peak power 800W /1200W 1000W 1500W Nominal MAX /Peak SPL 129dB 129dB Frequency Response( ±3dB) 42Hz - 20KHz 40Hz - 20KHz Crossover point 2.0 KHz 1.9 KHz Input Connector 8 Ohms 8 Ohms Dimension W*D*H (mm) 390×595×358 465×695×456 Net Weight (1pcs) 22kg 33kg -
-
. Mid or Larger clubs, disco bars hotel and restaurants
. Stadium Sports and mid. large exhibition spaces.
. Theater places performance expand sound systems.
. Audio & video presentations sound systems.
. Fixed Installations system and Live sound reinforcement -
