VT215 three way powerful line array speaker< back

zoom in zoom out

move up move left move right move bottom

  • Specifications
  • Feature
  • Application
  • Download
  • Print
  • VT series is large live concert high level line array speaker ,It build in customized neodymium woofer & driver imported from USA.

    Low distortion, high sensitivity, strong&powerful! VT215 is advanced technology and innovation representative.


    Product feature:

    1). Baltic birch 15&18mm plywood cabinet

    2). textured polyurethane painted, moisture-proof, corrosion resistance,wear-resisting, suit for outdoor touring.

    3). Imported from USA HF, LF component. (high performance, high dynamic)

    4). VT is full size cabinet, HF is crystal, LF is powerful and stronger.

    5). Easy install, plug and play


    Products Model:    VT212    VT215    VT225   VT218S
    LF neodynium unit  2 x 12" (φ75mm)   2 x 15"    2 x 15"   2 x 18"
    MF mid woofer  4X6.5" (φ38mm)     4x 6.5"    4X8" neo    /
    HF neodymium drivers  2X3"   2X3"    2X3"   /
    Horn & Exit throat Size  2x1.5"(38mm)   2x1.5"   2x1.5"   /
    Dispersion Angle  H90°x Vertical    H90°x Vertical    H90°x Vertical    /
    RMS / program  1500W/3000W    1700W/3400W    2000W/4000W  2000W/4000W
    Peak power  4500W   5100W   6000W  6000W
    Nominal MAX /Peak SPL  135dB   136dB   138dB  129dB
    Frequency Response( ±3dB)  64Hz - 19KHz    60Hz - 19KHz    60Hz - 19KHz    25Hz - 250Hz
    Crossover Frequency point  1200hz, 2.1KHz   1200hz, 2.1KHz   1200hz, 2.1KHz   150 Hz
    Nominal Impedance  LF/ MF: 8 ohm; HF: 16ohm   LF/ MF: 8 ohm; HF: 16ohm   LF/ MF: 8 ohm; HF: 16ohm   4 Ohms
    Input output Connector   2 *NL8    2 *NL8    2 *NL8    2 *NL4
    Dimension (mm)  1080x530x380    1260x560x 490   1195*560*610   1260 x560 x 700
    Net Weight   (1pcs)  56 kg    65kg   70KG   87kg

  • Feature:

    1. Birch plywood 18mm, weather-resistant, scratch-resistant;

    2. Wave guide horn, dispersion AngleH90°x Vertical splay Angle

    3. Imported drivers, powerful & perfect sound.

    4. Large & multipurpose enclosed. It can hang in the air or stack on the ground.

    5. Black or white color

    6. Normal impedance: 8ohm

    7. Hardware is included, just plug and play

    8. Net weight: 65KG

  • Application:

    Theater places expand sound systems.

    Touring FOH system

    Audio & video presentations sound system

    Mobile or permanently live concert reinforcement

  • Power amplifier and line array speaker
  • amplifier and speaker
